Thread Mill, Solid Carbide, Full Form, UN(UNC, UNF, UNEF), TiSiN Coated

£28.57 GBP

In offerta Esaurito

Imposte incluse. Spese di spedizione calcolate al check-out.

Quantità

Suitable Working Material:

General steel (P) General steel (P) Cast iron (K)

Tungsten Carbide Tools

Shipping Policy

Expected Time

Handling time (days), if in stock, it will take 0-2 days to prepare the package. If you are customizing some tools, it typically will take 0-7 days to prepare the package.

Transit time (days) to your address in 7-15 days. It will be shipped from China by International Express Delivery.

Region	Countries	Delivery Time
North America	United States, Canada, Mexico	7-15 business days
South America	Brazil, Argentina, Chile	10-20 business days
Asia	Japan, South Korea, Philippines, Indonesia, India, Pakistan	7-15 business days
Europe	Turkey, Russia, Poland, Germany, France, Italy, Belgium, Spain, United Kingdom	10-20 business days
Middle East	United Arab Emirates, Saudi Arabia	10-20 business days

Free Shipping Policy

Order over 79GBP/100USD will get free shipping, otherwise you need to pay 7.9GBP/10USD for the shipment fee.

If you need expedite express service, we'll provide UPS/DHL as well but you need add some shipment fee depend on the weight . It will take only 3-5 days to you.

Countries we are selling to

We are selling to countries: UK, US, Australia, Canada, Israel, India, Japan, Malaysia, New Zealand, Norway, Singapore, South Korea, Switzerland, Thailand, UAE, Vietnam, Austria, Belgium, Bulgaria, Croatia, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden,

💬

Need Assistance or Customize

Contact our Expert Team

Whatsapp Sales

447784618056

24/7

Email Us

sales@ky-tools.com

Our team is ready to assist

Visualizza dettagli completi

Description:

Spec	Type	Major Diameter	Threads Per Inch	Cut Diameter (Inch)	Neck Length (Inch)	Shank Diameter (Inch)	Overall Length (Inch)	Cut Diameter (mm)	Neck Length (mm)	Shank Diameter (mm)	Overall Length (mm)
UNC 1/4-20	UNC	1/4	20	0.191	0.472	0.236	2.362	4.850	12.00	6	60
UNC 5/16-18	UNC	5/16	18	0.252	0.709	0.236	2.362	6.400	18.00	6	60
UNC 3/8-16	UNC	3/8	16	0.307	0.827	0.315	2.362	7.800	21.00	8	60
UNC 7/16-14	UNC	7/16	14	0.346	0.945	0.394	2.953	8.800	24.00	10	75
UNC 9/16-12	UNC	9/16	12	0.472	1.102	0.472	2.953	12.000	28.00	12	75
UNC 1/2-13	UNC	1/2	13	0.394	0.945	0.394	2.953	10.000	24.00	10	75
UNC 5/8-11	UNC	5/8	11	0.472	1.102	0.472	2.953	12.000	28.00	12	75
UNC 3/4-10	UNC	3/4	10	0.630	1.496	0.630	3.937	16.000	38.00	16	100
UNC 7/8-9	UNC	7/8	9	0.630	1.496	0.630	3.937	16.000	38.00	16	100
UNF 10-32	UNF	10	32	0.154	0.394	0.157	1.969	3.900	10.00	4	50
UNF 1/4-28	UNF	1/4	28	0.209	0.472	0.236	2.362	5.300	12.00	6	60
UNF 5/16-24	UNF	5/16	24	0.256	0.709	0.315	2.362	6.500	18.00	8	60
UNF 7/16-20	UNF	7/16	20	0.374	0.945	0.394	2.953	9.500	24.00	10	75
UNF 9/16-18	UNF	9/16	18	0.394	0.945	0.394	2.953	10.000	24.00	10	75
UNF 3/4-16	UNF	3/4	16	0.472	1.102	0.472	2.953	12.000	28.00	12	75
UNEF 5/16-32	UNEF	5/16	32	0.268	0.709	0.315	2.362	6.800	18.00	8	60

Fabbrica di frese CNC in metallo duro con attrezzature avanzate

Il nostro stabilimento è dotato dei più moderni macchinari CNC e utensili di precisione, garantendo la produzione di frese, punte e alesatori in metallo duro di alta qualità. Con oltre 30 anni di esperienza, garantiamo una produzione precisa, consegne rapide e spedizioni in tutto il mondo.

Contattaci per un preventivo
